— Vartech® DC Power Supplies
6005-2 60V / 5A × 2 Dual-Output Heavy-Duty Linear DC Regulated Power Supply
0–60 V, 0–5 A × 2 independent dual outputs — series & parallel tracking, preset V & I, high precision linear regulation.
Authorised Dealer - Genuine Vartech product
- Expert technical support
- Pan-India delivery
- Competitive pricing
About This Instrument
The Vartech 6005-2 is a dual-output transformer-based linear DC regulated power supply with two independent 0–60 V / 0–5 A channels. Like the 3010-2 it supports independent, series and parallel operation, auto series/parallel tracking, preset V & I, Output On/Off, and full protection including reverse-polarity. Suited for higher-voltage dual-rail applications in electronics labs, R&D and industrial test benches.
Key Features
- Two independent outputs: 0–60 V, 0–5 A each
- Auto series & parallel tracking
- Independent, series and parallel operation
- Preset voltage and current
- Output On/Off control
- Low ripple & noise, low temperature drift
- Reverse-polarity and overload protection
Technical Specifications
| Output | 0–60 V, 0–5 A × 2 (independent) |
| Type | Linear (transformer-based), Dual output |
| CV Line Regulation | ≤ 0.01 % + 3 mV |
| CV Load Regulation | ≤ 0.01 % + 3 mV (I ≤ 3 A) | ≤ 0.02 % + 5 mV (I > 3 A) |
| CC Line Regulation | ≤ 0.2 % + 3 mA |
| CC Load Regulation | ≤ 0.2 % + 3 mA (I ≤ 3 A) | ≤ 0.2 % + 5 mA (I > 3 A) |
| Protection | Constant current, short-circuit and reverse-polarity protection |
| Display | 3-digit LED (V and A) |
| Indication Accuracy | ± 1 % + 2 digits | Preset mode: ± 1 % + 8 digits |
| Power Supply | 220 V ±10 %, 50 Hz ±2 Hz |
| Operating Environment | 0–40 °C | RH < 80 % |
| Dimensions & Weight | 255 × 155 × 460 mm | Approx. 16 kg |
| Accessories | Power cord & instruction manual |
Specifications sourced from the official Vartech product catalogue. Download above for the full datasheet.
Interested in the Vartech 6005-2? Get a quote today.
Email us with your model, quantity and application — we respond within one business day.
