M 2101 True RMS Digital Clamp Multimeter 1000A AC DC
Professional True RMS clamp meter — 6000 counts, DC and AC current from 600 µA to 1000 A, frequency to 20 MHz.
Authorised Dealer - Genuine Vartech product
- Expert technical support
- Pan-India delivery
- Competitive pricing
About This Instrument
The Vartech M 2101 is the benchmark professional True RMS digital clamp meter in the Vartech range — a 6000-count auto/manual ranging instrument with a current measurement span of 600 µA through the test leads to 1000 A through the clamp jaw. True RMS measurement, DC current capability, frequency up to 20 MHz with a dedicated Hz/Duty button, capacitance, temperature and auto power off make it the only clamp meter most electrical engineers, automation professionals and industrial maintenance teams will ever need to carry.
Key Features
- True RMS measurement from 600 µA to 1000 A — the widest current span in the Vartech clamp range; True RMS gives correct readings on VFDs, motor drives and any non-sinusoidal AC load
- µA ranges (600 µA and 6000 µA) through the meter test leads — measure milliamp control currents and in-circuit electronics without a separate handheld multimeter
- DC current measurement — unlike AC-only clamp meters, measures solar panel strings, battery circuits, DC busbars and variable-speed drive DC links correctly
- Auto/manual ranging — auto mode for fast switching between tasks; manual mode for precision when needed, including selecting the correct µA range
- Frequency measurement up to 20 MHz with dedicated Hz/Duty button — diagnose VFDs, PWM controllers and switching circuits in both ACV and ACA modes without changing function
- Capacitance up to 6000 µF and temperature to 1000 °C — complete component and environmental measurement capability alongside the clamp function
- Auto Power Off and Relative measurement — intelligent field-ready features that save battery and simplify comparative measurements on large cable runs
Technical Specifications
| Display | 3⅚ Digits, 6000 Counts, Backlight |
| True RMS | Yes |
| Ranging | Auto / Manual |
| DC Voltage | 600 mV / 6 V / 60 V / 600 V / 1000 V | Accuracy: ±(0.5% rdg + 3 digits) |
| AC Voltage (True RMS) | 600 mV / 6 V / 60 V / 600 V / 750 V | Accuracy: ±(0.8% rdg + 5 digits) |
| AC & DC Current (True RMS AC) | 600 µA / 6000 µA / 60 A / 600 A / 1000 A | Accuracy: ±(0.8% rdg + 10 digits) | Note: µA ranges measured via test leads |
| Resistance | 600 Ω / 6 KΩ / 60 KΩ / 600 KΩ / 6 MΩ / 60 MΩ | Accuracy: ±(0.8% rdg + 5 digits) |
| Capacitance | 60 nF / 600 nF / 6 µF / 60 µF / 600 µF / 6000 µF |
| Frequency | 10 Hz / 100 Hz / 1 KHz / 10 KHz / 100 KHz / 1 MHz / 20 MHz | Hz/Duty button for switching during ACV & ACA measurement |
| Temperature | −20 °C to 1000 °C (0 °F to 1832 °F) |
| Other Functions | Diode Test, Continuity Test, Data Hold, Relative Measurement, Auto Power Off, Torch |
| Accessories | Test leads, carrying pouch, temperature probe, user manual, battery |
| Dimensions & Weight | 280 × 70 × 45 mm | ~300 g (including battery) |
Specifications are sourced from the official Vartech product catalogue. Download the catalogue above for the full datasheet.
