V 2002+ Smart Clamp Meter mA Leakage Tester True RMS
Dedicated mA Leakage Tester and Smart Clamp Meter — measures earth leakage from 600 mA, DC current, frequency to 10 MHz, Type-C rechargeable.
Authorised Dealer - Genuine Vartech product
- Expert technical support
- Pan-India delivery
- Competitive pricing
About This Instrument
The Vartech V 2002+ is a dedicated mA Leakage Tester and Smart Clamp Meter combined — the only Vartech clamp meter engineered to measure earth leakage currents as low as 200 mA through its clamp jaw. Where standard clamp meters need 40 A or more before their readings are meaningful, the V 2002+ resolves from 600 mA, making it indispensable for earth fault investigation, RCD and ELCB verification, neutral current measurement and installation quality checks. DC current measurement, frequency and duty cycle up to 10 MHz, REL mode and a Type-C rechargeable battery complete its professional specification.
Key Features
- mA-level clamp current measurement from 600 mA AC — the defining feature; resolves earth leakage, neutral imbalance and RCD test currents that are completely invisible on standard 400 A or 1000 A clamp meters
- REL (Relative) measurement — zero out background leakage current and display only the incremental change; essential for precise earth fault location in installations with background load current
- DC current measurement (6 A / 60 A) — measure solar panel strings, battery systems and DC distribution currents through the clamp jaw, not through the test leads
- Frequency and duty cycle up to 10 MHz — diagnose VFD outputs, switching power supplies and PWM controllers directly in clamp mode; unique in this class of instrument
- True RMS 6000-count fully automatic ranging — accurate on any waveform; essential for correct leakage readings in installations with VFDs and electronic ballasts that distort the current waveform
- NCV and Live Wire detection — positive conductor identification before working in complex multi-circuit panels
- Type-C rechargeable battery — no disposable cells; same platform and charging cable as the V 2001+
Technical Specifications
| Display | 3⅚ Digits, 6000 Counts |
| True RMS | Yes |
| Ranging | Fully Automatic |
| DC Voltage | 600 mV / 6 V / 60 V / 600 V / 1000 V | Accuracy: ±(0.5% rdg + 3 digits) |
| AC Voltage (True RMS) | 6 V / 60 V / 600 V / 750 V | Accuracy: ±(0.8% rdg + 3 digits) |
| AC Current (True RMS) — Leakage | 600 mA / 6 A / 60 A | Accuracy: ±(4% rdg + 20 digits) for 200–600 mA range |
| DC Current | 6 A / 60 A | Accuracy: ±(2% rdg + 30 digits) |
| Resistance | 600 Ω / 6 KΩ / 60 KΩ / 600 KΩ / 6 MΩ / 60 MΩ | Accuracy: ±(0.8% rdg + 5 digits) |
| Capacitance | 6 nF / 60 nF / 600 nF / 6 µF / 60 µF / 600 µF / 6 mF / 60 mF |
| Frequency / Duty Cycle | 6 Hz – 10 MHz | Max. input: 250 V |
| Temperature | −20 °C to 1000 °C (−4 °F to 1832 °F) |
| Other Functions | NCV Test, Live Wire Test, Diode Test, Continuity Test, REL Measurement, Display Brightness Adjustment, Auto Power Off, Data Hold, Low Battery Indication |
| Battery | Built-in rechargeable, Type-C USB charging |
| Accessories | Test leads, temperature probe, carrying pouch, user manual, battery charging cable |
| Dimensions & Weight | 170 × 64 × 26 mm | ~150 g (including battery) |
Specifications are sourced from the official Vartech product catalogue. Download the catalogue above for the full datasheet.
