CIE/444 Insulation Tester — Metal Body, Hand-Driven
Hand-cranked analog insulation tester in anti-magnetic aluminium body — no batteries required. 100 V to 5000 V.
CIE® Guarantee
- CIE® Registered Trade Mark
- Calibrated Before Despatch
- 12-Month Warranty
- Made in India
- Custom Ranges Available
About This Instrument
The CIE/444 is a hand-driven generator-type insulation tester for direct-reading insulation resistance measurement on electrical machines, rotating plant, switchgear, cables, transformers, and industrial installations. Power is generated entirely by the operator via a collapsible hand crank — no batteries or external power source are required. A centrifugal governor (clutch) holds output voltage constant regardless of crank speed. The instrument features a high-sensitivity cross-coil indicator, anti-parallax mirror scale, and anti-magnetic aluminium body. A guard terminal and externally accessible infinity adjuster are provided on instruments with insulation range 1000 megohms and above. Conforms to ISS: 2992/1987. Quick response: 3 seconds.
Technical Specifications
| Specification | Value |
|---|---|
| Body | Anti-magnetic aluminium (pressure die-cast) |
| Generator Type | Hand-driven, silent A.C. generator with centrifugal governor (clutch) |
| Scale Length | 90 mm (approx.) |
| Accuracy | Conforms to ISS: 2992-1987 |
| Rotation Speed | 160 r.p.m. or more |
| Response Time | 3 seconds |
| Weight | 2.5 kg (approx.) |
| Dimensions (L×W×H) | 110 × 128 × 195 mm (approx.) |
| Rated Voltages Available | 100 V / 250 V / 500 V / 1000 V / 2500 V / 5000 V |
| Warranty | 12 months against manufacturing defects |
Build to Order
Specify the required rated voltage and resistance range when ordering. Other ranges manufactured to specific requirement.
Voltage & Resistance Range — Ordering Combinations
| Rated Voltage | Resistance Range |
|---|---|
| 100 V | 0–20 MΩ |
| 100 V | 0–50 MΩ |
| 100 V | 0–100 MΩ |
| 250 V | 0–50 MΩ |
| 250 V | 0–100 MΩ |
| 250 V | 0–250 MΩ |
| 500 V | 0–100 MΩ |
| 500 V | 0–200 MΩ |
| 500 V | 0–500 MΩ |
| 500 V | 0–1000 MΩ |
| 500 V | 0–2000 MΩ |
| 1000 V | 0–100 MΩ |
| 1000 V | 0–200 MΩ |
| 1000 V | 0–500 MΩ |
| 1000 V | 0–1000 MΩ |
| 1000 V | 0–2000 MΩ |
| 2500 V | 0–1000 MΩ |
| 2500 V | 0–2000 MΩ |
| 2500 V | 0–2500 MΩ |
| 2500 V | 0–5000 MΩ |
| 2500 V | 0–10000 MΩ |
| 2500 V | 0–20000 MΩ |
| 2500 V | 50–50000 MΩ |
| 5000 V | 0–5000 MΩ |
| 5000 V | 0–10000 MΩ |
| 5000 V | 0–20000 MΩ |
| 5000 V | 50–50000 MΩ |
Specify the required rated voltage and resistance range when ordering. Other ranges manufactured to specific requirement.
Additional Options
- Carrying case (metal body, CIE/444) — at extra cost
- Testing leads, 1m (up to 1000 V) — at extra cost
- Testing leads, 2m (up to 1000 V) — at extra cost
- H.V. testing leads, 2m — general — at extra cost
- H.V. testing leads, 2m — special — at extra cost
- Dual voltage & dual insulation range option — at extra cost
- Single voltage, dual insulation range option — at extra cost
- Continuity range (500 V/1000 V only) on single-voltage, single-range instruments — at extra cost
- Continuity range (500 V/1000 V only) on dual-voltage, dual-range instruments — at extra cost
- Any other range — on request
Key Applications
- Electrical maintenance of rotating plant equipment and stationary apparatus
- Insulation control and switching equipment checks
- Distribution network and communication cable insulation testing
- Transformer and insulator testing; industrial installation checks
- Locating intermittent shorts, defective connections, and developing insulation failures
